Supermicro AOC-S3908L-H8IR-16DD-O 8-Port Plug-in Card 14W SAS Controller
Overview
The Supermicro AOC-S3908L-H8IR-16DD-O is a low-profile internal RAID adapter card designed for enterprise-class server and storage systems. It features 8 internal ports with support for 12Gb/s SAS and 6Gb/s SATA drives, and uses a PCIe 4.0 interface for high-speed data transfer. This model is optimized for managing up to 16 drives with an expander.
Specifications
Model Number: AOC-S3908L-H8IR-16DD-O
Brand: Supermicro
Alt Part Number(s): AOC-S3908L-H8IR-16DD-O
Product Type: SAS Controller
Technical Description
Brand: Supermicro
Model Number: AOC-S3908L-H8IR-16DD-O
Total Number of SAS Ports: 8
Number of SAS Ports (Internal): 8
Maximum Data Transfer Rate: 12Gbit/s
Controller Type: 12Gb/s SAS
Controller Chip: Broadcom 3908L
Onboard Cache: 8GB DDR4 2666MHz
Interface: PCI Express 4.0
Power consumption: 14W
Raid levels: 0, 1, 5, 6, 10, 50, 60, and JBOD
Output Voltage: 208 - 230 V AC
Protocols: Web, SNMP, Telnet
Form Factor: Plug-in Card
*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
