Overview

The Vertiv Geist MNU3E1R6-12CF18-3TL6A0H10-S (also known by the model number NU30206) is a 1U horizontal switched rack power distribution unit (rPDU) designed for data center environments. It provides high-precision power distribution with individual outlet switching and monitoring capabilities to maximize IT equipment uptime.



Specifications

Model Number:  MNU3E1R6-12CF18-3TL6A0H10-S

Brand:  Vertiv

Alt Part Number(s):  NU30206

Product Type:  Power Distribution Unit

Technical Description

Brand:  Vertiv

Model Number:  MNU3E1R6-12CF18-3TL6A0H10-S

Series:  rPDU

Input Phase:  Single Phase

Input Current:  30A

Input Voltage Range:  200 – 240V AC

Input Connector:  NEMA L6-30P

Frequency:  50 - 60Hz

Output Voltage:  208V AC

Outlets: 12 x Combination C13/C19

Network Connectivity:  RJ-45 Ethernet

Power Capacity:  4.9k W

Form Factor:  2U Rackmount

Height:  1.7"

Width:  17"

Depth:   12"

*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
