Overview





Specifications

Model Number: B7136T70AV12E8HR-2T

Brand:  Tyan

Alt Part Number(s):  B7136T70AV12E8HR-2T

Product Type:  Server



Technical Description

Brand:  Tyan

Model: B7136T70AV12E8HR-2T

Model: Thunder SX TS70A-B7136

Cabinet Form Factor: 2U

Processor Type: Intel Xeon

Processor Manufacturer: Intel

Max Supported CPUs: 2

Chipset: Intel C741

RAM Technology: DDR5

RAM Slots: 16 total

Max Supported RAM: 2048 GB

Drive Bay Sizes: 3.5", 2.5"

Drive Interfaces: SATA 6 Gb/s, SAS 12 Gb/s, NVMe

Drive Bays: 20

RAID Support: RAID 0, 1, 5, 10

Network Protocol: Gigabit Ethernet

Power Supply Type: Redundant

Power Supplies Installed: 2

Voltage Requirement: AC 100–127V / 13A or AC 200–240V / 10A

Interfaces & Connections: USB 3.2 Gen1, RJ-45, DB-9 COM, D-Sub 15-pin (VGA)

Expansion Slots:

1 × PCIe Gen5 x4 slot

2 × PCIe Gen5 x8 slots

2 × PCIe Gen5 x16 slots

1 × PCIe Gen5 x16 OCP 3.0 mezzanine slot

RoHS Compliant: Yes



*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
