Overview

The Supermicro SuperServer SYS-5019P-MTR is a 1U rackmount barebone system designed for enterprise workloads, featuring Intel C622 chipset support for Xeon Platinum, Gold, Silver, and Bronze processors and up to 2TB of DDR4-2933 memory across eight slots. It offers robust connectivity and expansion with 10 SATA interfaces, RAID support, 10Gb Ethernet, AST2500 graphics, and dual 400W power supplies for high reliability.



Specifications

Model Number:  SYS-5019P-MTR

Brand:   Supermicro

Alt Part Number(s):    SYS-5019P-MTR

Product Type:  Server



Technical Description

Brand:  Supermicro

Model:  SYS-5019P-MTR

Number of Processors Supported: 1

Processor Socket: Socket P LGA-3647

Processor Supported: Xeon Platinum, Xeon Gold, Xeon Silver, Xeon Bronze

64-bit Processing: Yes

Chipset Manufacturer: Intel

Chipset Model: C622

Maximum Memory Supported: 2 TB

Memory Technology: DDR4 SDRAM

Memory Standard: DDR4-2933/PC4-23466

Total Number of Memory Slots: 8

Supported Storage Drive Interfaces: Serial ATA III

Supported Storage Drive Types: HDD

Controller Type: Serial ATA/600

RAID Supported: Yes

Graphics Controller Model: AST2500

Ethernet Technology: 10 Gigabit Ethernet

Number of Total Expansion Bays: 4

Number of 3.5" Bays: 4

Total Number of Expansion Slots: 1

Number of PCI Express x16 Slots: 1

Total Number of USB Ports: 11

Number of USB 3.0 Ports: 3

Number of Onboard USB 2.0 Ports: 4

Number of SATA Interfaces: 10

Number of VGA Ports: 1

Input Voltage: 120 V AC, 230 V AC

Number of Power Supplies Installed: 2

Maximum Power Supply Wattage: 400 W

Frequency: 50 Hz, 60 Hz

Color Family: Black

Product Color: Black

Form Factor: 1U Rackmount

Height: 1.7"

Width: 17.2"

Depth: 19.9"

Weight (Approximate): 17.60 lb
