Overview

The MBI-6219B-T41N is a dual-node MicroBlade module that packs two Intel Xeon D-2141I servers into one sled, each with 8 cores/16 threads, up to 128 GB ECC memory, flexible internal storage (2.5″ SATA/HDD/SSD or NVMe U.2 plus M.2 NVMe), and dual 10 GbE networking — ideal for high-density server deployments in blade chassis.



Specifications

Model Number:  MBI-6219B-T41N

Brand:  Supermicro

Alt Part Number(s):  MBI-6219B-T41N

Product Type:  Server

Technical Description

Brand:  Supermicro

Model Number:  MBI-6219B-T41N

Processor Type:  Intel Xeon

Processor Model:  D-2141I

Processor Core:  8 Cores/16 threads

Processor Speed:  2.2GHz

Processor Socket:  FCBGA 2518

Storage Interfaces:  2.5″ SATA HDDs/SSDs or U.2 NVMe SSDs

Network:  Dual 10GbE LAN ports

Motherboard:  MBD-B2SD2-8C-TF

Memory Supported:  128GB

Memory Speed:  2133MHz

Memory Type:  DDR4

Memory Slots:  4 DIMM

Expansion Slots:  1 × PCIe 4.0 ×16

Error Detection:  ECC

TDP:  65W

Form Factor:  MicroBlade

*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
