Overview

The Supermicro MBD-X10SDV-12C-TLN4F+-O is a compact Mini-ITX motherboard featuring an integrated 12-core Intel Xeon D-1557 processor. The "+ " in the model name distinguishes it by featuring dual 10G SFP+ ports instead of standard 10Gbase-T copper ports, making it ideal for high-speed fiber network integration.



Specifications

Model Number:  MBDX10SDV12CTLN4F+-O

Brand:  Supermicro

Alt Part Number(s):  MBDX10SDV12CTLN4F+-O

Product Type:  Motherboard

Technical Description

Brand:  Supermicro

Model Number:  MBDX10SDV12CTLN4F+-O

Processor Type:  Intel Xeon

Processor Model:  D‑1557

Processor Speed:  1.5GHz (2.1GHz)

Processor Core:  12 Core/24 Threads

Processor Socket:  FCBGA‑1667

Storage Interfaces:  6 × SATA3 (6 Gbps) ports

Network:  2 × 10 GbE SFP+ via SoC, 2 × 1 GbE via Intel i350‑AM2 controller

USB:  2 × USB 3.0 ports, 4 × USB 2.0 via headers

RAID:  RAID 0, 1, 5, and 10

Graphics:  ASPEED AST2600 BMC

Memory Capacity:  64GB

Memory Supported:  128GB

Memory Speed:  2133MHz

Memory Type:  DDR4

Memory Slots:  4 DIMM slots

Expansion Slots:  1 × PCIe 3.0 ×16

Error Detection:  ECC

Power Capacity:  45W

Power Input:  12 V DC

Form Factor:  Mini‑ITX

*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
