Overview

The Supermicro MBD-X11SRL-F-B is a high-performance single-socket server motherboard featuring the Intel C422 chipset, specifically designed for workstation and high-performance computing (HPC) environments. The "-B" suffix indicates bulk packaging, which typically includes the motherboard, an I/O shield, and two SATA cables, but lacks the retail box and full accessory set.



Specifications

Model Number:  MBD-X11SRL-F-B

Brand:  Supermicro

Alt Part Number(s):  MBD-X11SRL-F-B

Product Type:  Motherboard

Technical Description

Brand:  Supermicro

Model Number:  MBD-X11SRL-F-B

Series:  W-2100/W-2200

Processor Type:  Intel Xeon

Processor Core:  18 Cores/36 threads

Processor Socket:  LGA-2066 (Socket R4)

Chipset Type:  Intel C422

Storage Interfaces:  8 × SATA3 (6 Gbps)

Network:  Dual Gigabit Ethernet LAN ports powered by the Intel i210 controller

USB:  2 USB 3.0 ports (rear), 6 USB 2.0 ports, and 2 COM ports

RAID:  RAID 0, 1, 5, and 10

Graphics:  ASPEED AST2500 BMC

Memory Supported:   1TB

Memory Type:  DDR4

Memory Slots:  8 DIMM slots

Expansion Slots:  6

Error Detection:  ECC

TDP:  165W

Form Factor:  ATX
