Overview

The Supermicro MBD-X11SDW-16C-TP13F-B is a high-performance proprietary WIO motherboard featuring an integrated 16-core Intel Xeon D-2183IT processor, designed for embedded networking and storage systems. The "-B" suffix indicates the Bulk Pack version, typically used by system integrators.



Specifications

Model Number:  MBD-X11SDW-16C-TP13F-B

Brand:  Supermicro

Alt Part Number(s):  MBD-X11SDW-16C-TP13F-B

Product Type:  Motherboard

Technical Description

Brand:  Supermicro

Model Number:  MBD-X11SDW-16C-TP13F-B

Processor Type:  Intel Xeon

Processor Model:  D-2183IT

Processor Core:  16 Cores/32 threads

Processor Socket:  FCBGA-2518

Storage Interfaces:  4 × SATA3 (6 Gb/s)

Network:  2 x 10GBase-T (RJ45) ports and 2 x 10G SFP+ ports, 9 x RJ45

RAID:  RAID 0, 1, 5, and 10

Graphics:  ASPEED AST2500 BMC

Memory Capacity:  256GB

Memory Supported:   512GB

Memory Type:  DDR4

Memory Slots:  4 DIMM slots

Expansion Slots:  1 × PCIe 3.0 ×32

Error Detection:  ECC

TDP Support:  Up to 100W

Power Input:  12V DC

Form Factor:  Proprietary WIO

*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
