Overview

The Supermicro MBD-X11SDV-8C-TP8F-O is a high-performance Flex-ATX server motherboard featuring an integrated 8-core Intel Xeon D-2146NT processor. It is specifically optimized for embedded networking, mid-range storage appliances, and edge computing environments.



Specifications

Model Number:  MBD-X11SDV-8C-TP8F-O

Brand:  Supermicro

Alt Part Number(s):  MBD-X11SDV-8C-TP8F-O

Product Type:  Motherboard

Technical Description

Brand:  Supermicro

Model Number:  MBD-X11SDV-8C-TP8F-O

Processor Type:  Intel Xeon

Processor Model:  D-2146NT

Processor Speed:  2.30GHz (3.0GHz)

Processor Core:  8-Cores, 16 threads

Processor Cache:  11MB

Storage Interfaces:  12 SATA3 (6Gbps) ports

Network:  4 × 1 GbE + 2 × 10GBase‑T + 2 × 10G SFP+

USB:  2 × USB 3.0

RAID:  RAID 0, 1, 5, and 10

Graphics:  ASPEED AST2500 BMC

Memory Capacity:  256GB

Memory Supported:  512GB

Memory Type:  DDR4

Memory Slots:  8 DIMM slots

Expansion Slots:  1 × PCIe 3.0 x16, 1 × PCIe 3.0 x8, 1 × Mini-PCIe

Error Detection:  ECC

TDP:  80W

Form Factor:  Flex ATX
