Overview

The Supermicro MBD-X11SDV-8C+-TLN2F-O is a high-performance Mini-ITX server motherboard featuring an integrated 8-core Intel Xeon D-2141I processor. The "-O" suffix indicates the Retail Pack version, which typically includes full documentation and accessories such as SATA cables and an I/O shield.



Specifications

Model Number:  MBD-X11SDV-8C+-TLN2F-O

Brand:  Supermicro

Alt Part Number(s):  MBD-X11SDV-8C+-TLN2F-O

Product Type:  Motherboard

Technical Description

Brand:  Supermicro

Model Number:  MBD-X11SDV-8C+-TLN2F-O

Processor Type:  Intel Xeon

Processor Model:  D-2141I

Processor Speed:  2.20GHz

Processor Cache:  11MB

Processor Core:  8Cores, 16 threads

Processor Socket:  FCBGA-2518

Storage Interfaces:  8 × SATA3 (6 Gb/s)

Network:  Dual 10GBase-T (RJ45) ports integrated via the Intel SoC (Intel X557)

USB:  2 × USB 3.0 (rear), 2 × USB 2.0 (via header)

RAID:  RAID 0, 1, 5, and 10

Graphics:  ASPEED AST2500 BMC

Memory Capacity:  256GB

Memory Supported:  512GB

Memory Speed:  2133MHz

Memory Type:  DDR4

Memory Slots:  4 DIMM slots

Expansion Slots:  1 × PCIe 3.0 x8, PCIe 3.0 x4 NVMe

Error Detection:  ECC

Fan Headers:  Up to 3 × 4-pin PWM fan headers

TDP:  65W

Power Input:  12V DC

Form Factor:  Mini-ITX

*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
