Overview

The Supermicro MBD-X11SDV-4C-TLN2F-O is a high-performance Mini-ITX server motherboard featuring an integrated 4-core Intel Xeon D-2123IT processor. It is engineered for high-density compute tasks such as edge computing, virtualization, and network security appliances.



Specifications

Model Number:  MBD-X11SDV-4C-TLN2F-O

Brand:  Supermicro

Alt Part Number(s):  MBD-X11SDV-4C-TLN2F-O

Product Type:  Motherboard

Technical Description

Brand:  Supermicro

Model Number:  MBD-X11SDV-4C-TLN2F-O

Processor Type:  Intel Xeon

Processor Model:  D-2123IT

Processor Speed:  2.20GHz (3.00GHz)

Processor Cache:  8MB

Processor Core:  4Cores / 8 threads

Storage Interfaces:  8 × SATA3 (6 Gb/s)

Network:  Dual 10GBase-T (RJ45) ports integrated via the Intel SoC

USB:  2 × USB 3.0, 2 × USB 2.0

RAID:  RAID 0, 1, 5, and 10

Graphics:  ASPEED AST2500 BMC

Memory Capacity:  256GB

Memory Supported:  512GB

Memory Speed:  2400MHz

Memory Type:  DDR4

Memory Slots:  4 DIMM slots

Expansion Slots:  1 × PCIe 3.0 x8

Error Detection:  ECC

Fan Headers:  Multiple 3 PWM fan

TDP:  60W

Power Input:  12 V DC

Form Factor:  Mini-ITX
