Overview

The Supermicro MBD-X11SDV-16C-TP8F-O is a high-performance Flex-ATX server motherboard featuring an integrated 16-core Intel Xeon D-2183IT processor. It is designed for ultra-dense, low-power applications such as intelligent edge network appliances, mid-range networking, and storage servers.



Specifications

Model Number:  MBD-X11SDV-16C-TP8F-O

Brand:  Supermicro

Alt Part Number(s):  MBD-X11SDV-16C-TP8F-O

Product Type:  Motherboard

Technical Description

Brand:  Supermicro

Model Number:  MBD-X11SDV-16C-TP8F-O

Processor Type:  Intel Xeon

Processor Model:  D-2183IT

Processor Core:  16Cores / 32 threads

Processor Speed:  2.20GHz (3.00GHz)

Storage Interfaces:  12 × SATA3 + 2 × U.2 + 2 × M.2 (PCIe/SATA)

Network:  2 × 10GBASE-T + 2 × 10G SFP+ + 4 × 1 GbE

RAID:  RAID 0, 1, 5, and 10

Graphics:  ASPEED AST2500 BMC

Memory Capacity:  256GB

Memory Supported:  512GB

Memory Type:  DDR4

Memory Slots:  4 DIMM slots

Expansion Slots:  PCIe 3.0 ×16, ×8, Mini-PCIe

Error Detection:  ECC

Power Input:  12 V DC

TDP:  100W

Form Factor:  Flex ATX

*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
