Overview

The Supermicro MBD-X11SDV-16C-TLN2F-O is a high-performance Mini-ITX server motherboard featuring an integrated 16-core Intel Xeon D-2183IT processor. Part of the X11SDV series, it is optimized for high-density compute, networking, and storage in space-constrained environments such as edge computing and network security appliances.



Specifications

Model Number:  MBD-X11SDV-16C-TLN2F-O

Brand:  Supermicro

Alt Part Number(s):  MBD-X11SDV-16C-TLN2F-O

Product Type:  Motherboard

Technical Description

Brand:  Supermicro

Model Number:  MBD-X11SDV-16C-TLN2F-O

Processor Type:  Intel Xeon

Processor Model:  D‑2183IT

Processor Core:  16Cores / 32 threads

Processor Cache:  22MB

Storage Interfaces:  8 SATA3 (6Gbps) ports

Network:  Integrated Intel Dual 10GBase‑T LAN ports

USB:  2 USB 3.0 ports (rear) and 2 USB 2.0 ports

RAID:  RAID 0, 1, 5, and 10

Graphics:  ASPEED AST2500 BMC

Memory Capacity:  256GB

Memory Supported:  512GB

Memory Type:  DDR4

Memory Slots:  4 DIMM slots

Expansion Slots:  1 × PCIe 3.0 x8

Error Detection:  ECC

TDP:  100W

Form Factor:  Mini‑ITX
