Overview

The MBD-X11SCZ-Q-B is a micro-ATX motherboard targeting desktop-class and small server use cases — combining support for 8th/9th Gen Intel® CPUs, dual Gigabit LAN, RAID storage, M.2 NVMe/SATA, and multiple display outputs. It’s well-suited for workstations, network appliances, and business PCs requiring robust connectivity and moderate expansion.



Specifications

Model Number:  MBD-X11SCZ-Q-B

Brand:  Supermicro

Alt Part Number(s):  MBD-X11SCZ-Q-B

Product Type:  Motherboard

Technical Description

Brand:  Supermicro

Model Number:  MBD-X11SCZ-Q-B

Processor Type:  Intel Core i9/i7/i5/i3

Processor Socket:  LGA-1151 (Socket H4)

Processor Generation:  8th/9th Gen

Chipset Type:  Intel Q370

Storage Interfaces:  5 SATA3 (6Gbps) ports

Network:  Dual Gigabit Ethernet ports the Intel i210-AT and Intel PHY i219LM controllers

USB:  6 USB 3.1 Gen 2 ports,2 USB 3.1 Gen 1 ports, 7 USB 2.0 ports

RAID:  RAID 0, 1, 5, and 10

Audio:  Realtek ALC888S HD Audio

Graphics:  ASPEED AST2600 BMC

Memory Supported:  128GB

Memory Type:  DDR4

Memory Slots:  4 DIMM

Expansion Slots:  PCIe 3.0 x4

Error Detection:  non-ECC

TDP:  95W

Form Factor:  Micro-ATX

*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
