Overview

The Supermicro MBD-X11SCQ-B is ideal when you need a robust Micro-ATX platform with support for modern Intel 8th/9th Gen CPUs, good PCIe expansion, multiple display outputs, and enterprise-class features like RAID, TPM, and dual LAN controllers — suited for workstations, compact servers, kiosks, or industrial PCs with strong I/O flexibility.



Specifications

Model Number:  MBD-X11SCQ-B

Brand:  Supermicro

Alt Part Number(s):  MBD-X11SCQ-B

Product Type:  Motherboard

Technical Description

Brand:  Supermicro

Model Number:  MBD-X11SCQ-B

Processor Type:  Intel Core i9/i7/i5/i3

Processor Socket:  LGA-1151 (Socket H4)

Processor Generation:  8th/9th Gen

Chipset Type:  Intel Q370

Storage Interfaces:  6 SATA3 (6 Gbps) ports

Network:  Dual Gigabit Ethernet ports the Intel i210-AT and Intel PHY i219LM controllers

Video Outputs:  1 DisplayPort, 1 HDMI, 1 DVI-D, and 1 eDP

USB:  total of 10 USB 3.2 Gen2 ports and 6 USB 2.0 ports

Audio:  Integrated 7.1 HD Audio

RAID:  RAID 0, 1, 5, and 10

Memory Supported:  64GB

Memory Type:  DDR4

Memory Slots:  4 DIMM slots

Expansion Slots:  1 × PCIe 3.0 ×16,1 × PCIe 3.0 ×1,2 × PCIe 3.0 ×4

Error Detection:  Non-ECC

TDP:  95W

Form Factor:  Micro-ATX
