Overview

The Supermicro MBD-X11SCA-W-O is a high-end workstation motherboard featuring the Intel C246 chipset and integrated Wi-Fi. The "-O" suffix indicates the Retail Pack version.



Specifications

Model Number:  MBD-X11SCA-W-O

Brand:  Supermicro

Alt Part Number(s):  MBD-X11SCA-W-O

Product Type:  Motherboard

Technical Description

Brand:  Supermicro

Model Number:  MBD-X11SCA-W-O

Series:  E-2100/E-2200

Processor Type:  Intel Xeon

Processor Socket:  LGA-1151 (Socket H4)

Processor Generation:  8th/9th Gen

Chipset Type:  Intel C246

Storage Interfaces:  8 SATA3 (6Gbps) ports

Network:  Dual Gigabit Ethernet (1GbE) LAN ports (Intel i210-AT and i219LM)

USB:  USB 3.1 Gen 2 (Type-A and Type-C), USB 3.1 Gen 1, and USB 2.0

Video Output:  1 HDMI 2.0, 1 DisplayPort 1.2, 1 DVI-D, and 1 VGA port

RAID:  RAID 0, 1, 5, and 10

Wireless:  Integrated Wi-Fi 802.11ac and Bluetooth 5.0

Memory Supported:  128GB

Memory Speed:  2666MHz

Memory Type:  DDR4

Memory Slots:  4 DIMM slots

Expansion Slots:  2 x PCIe 3.0 x16

Error Detection:  ECC

TDP:  95W

Form Factor:  ATX
