Overview

The Supermicro MBD-X10SDV-12C+-TLN4F-O is a high-performance Mini-ITX server motherboard featuring an integrated 12-core Intel Xeon D-1567 processor. This board is designed for low-power, high-density infrastructure applications such as network appliances and compact 1U servers.



Specifications

Model Number:  MBD-X10SDV-12C+-TLN4F-O

Brand:  Supermicro

Alt Part Number(s):  MBD-X10SDV-12C+-TLN4F-O

Product Type:  Motherboard

Technical Description

Brand:  Supermicro

Model Number:  MBD-X10SDV-12C+-TLN4F-O

Processor Type:  Intel Xeon

Processor Model:  D‑1567

Processor Core:  12 Cores/24 threads

Processor Cache:  18 MB L3

Processor Socket:  BGA‑1667

Storage Interfaces:  10 × SATA3 + 5 × NVMe internal + 2 × M.2

Network:  2 × 10GBase‑T + 2 × 1GbE + IPMI

RAID:  RAID 0, 1, 5, and 10

Graphics:  ASPEED AST2400 BMC

Memory Capacity:  64GB

Memory Supported:  128GB

Memory Type:  DDR4

Memory Slots:  4 DIMM slots

Expansion Slots:  1 × PCIe 3.0 ×16; 1 × M.2 PCIe/SATA

Error Detection:  ECC

TDP:  65W

Form Factor:  Mini‑ITX

*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
