Overview

The Supermicro MBD-H12SSL-CT-O is an ATX server motherboard optimized for single-socket AMD EPYC 7000 series processors, featuring integrated 12Gbps SAS3 storage and 10GbE networking. The "-O" suffix denotes the Retail Pack version.



Specifications

Model Number:  MBD-H12SSL-CT-O

Brand:  Supermicro

Alt Part Number(s):  MBD-H12SSL-CT-O

Product Type:  Motherboard

Technical Description

Brand:  Supermicro

Model Number:  MBD-H12SSL-CT-O

Series:  7003 / 7002

Processor Type:  AMD EPYC

Processor Core:  64-Cores

Storage Interfaces:  8 × SATA3, 8 × SAS3, 2 × M.2 PCIe4.0 x4

Network:  Dual 10GBase-T + IPMI LAN

USB:  Up to 6 × USB 3.0

Graphics:  ASPEED AST2500 BMC

Memory Supported:   2TB

Memory Type:  DDR4

Memory Channels:  8-Channel

Memory Slots:  8 DIMM slots

Expansion Slots:  5 × PCIe4.0 ×16 + 2 × PCIe4.0 ×8

Error Detection:  ECC

Power Capacity:  270W

Form Factor:  ATX

*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
