Overview

The Supermicro MBD-H12SSL-CT-B is a high-performance ATX server motherboard designed for single-socket AMD EPYC 7002 and 7003 series processors. It is optimized for enterprise workloads and data centers, offering robust memory support and extensive PCIe 4.0 expansion.



Specifications

Model Number:  MBD-H12SSL-CT-B

Brand:  Supermicro

Alt Part Number(s):  MBD-H12SSL-CT-B

Product Type:  Motherboard

Technical Description

Brand:  Supermicro

Model Number:  MBD-H12SSL-CT-B

Series:  7003/7002

Processor Type:  AMD EPYC

Processor Core:  64-Cores

Storage Interfaces:  8 × SATA3 (6 Gb/s)

Network:  Dual 10GBase-T via Broadcom BCM57416

USB:  Up to 6 × USB 3.0 ports

RAID:  RAID 0, 1, and 10

Graphics:  ASPEED AST2500 BMC

Memory Supported:   2TB

Memory Speed:  3200MHz

Memory Channel:  8-Channel

Memory Type:  DDR4

Memory Slots:  4 DIMM slots

Expansion Slots:  5 PCI-E 4.0 x16 slots and 2 PCI-E 4.0 x8 slots

Error Detection:  ECC

TDP Support:  Up to 100W

Power Input:  12V DC

Form Factor:  ATX

*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
