Overview

The Supermicro MBD-H12DSI-NT6-O is a high-performance Extended ATX (E-ATX) server motherboard designed for dual AMD EPYC 7000 series processors. The "-O" suffix indicates a retail package, which typically includes the motherboard, an I/O shield, and two SATA cables.



Specifications

Model Number:  MBD-H12DSI-NT6-O

Brand:  Supermicro

Alt Part Number(s):  MBD-H12DSI-NT6-O

Product Type:  Motherboard

Technical Description

Brand:  Supermicro

Model Number:  MBD-H12DSI-NT6-O

Series:  7003/7002

Processor Type:  AMD EPYC

Processor Core:  64-Cores

Storage Interfaces:  10 x SATA3 (6Gbps) ports

Network:  Dual (10GbE) LAN ports powered by a Broadcom BCM57416 controller

USB:  2 x USB 3.0 ports and 2 x USB 2.0 ports

Graphics:  ASPEED AST2600 BMC

Memory Supported:   4TB

Memory Speed:  3200 MHz

Memory Channels:  8‑Channel

Memory Type:  DDR4

Memory Slots:  16 DIMM slots

Expansion Slots:  6 total PCIe 4.0 slots

Error Detection:  ECC

Power Capacity:  270W

Form Factor:  E-ATX

*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
