Overview

The Supermicro MBD-A2SDV-8C-LN10PF-O is a Flex-ATX server motherboard featuring an integrated 8-core Intel Atom processor and high-density networking with 10 total Gigabit LAN ports. The "-O" suffix indicates a Retail Pack.



Specifications

Model Number:  MBD-A2SDV-8C-LN10PF-O

Brand:  Supermicro

Alt Part Number(s):  MBD-A2SDV-8C-LN10PF-O

Product Type:  Motherboard

Technical Description

Brand:  Supermicro

Model Number:  MBD-A2SDV-8C-LN10PF-O

Processor Type:  Intel Atom

Processor Model:  C3758

Processor Core:  8 Cores / 8 threads

Processor Cache:  16MB

Processor Socket:  FCBGA-1310

Storage Interfaces:  5 × SATA3 (6 Gb/s) ports

Network:  8 x 1GbE RJ45 LAN ports,2 x 1GbE SFP,1 x Dedicated RJ45 IPMI LAN port

RAID:  RAID 0, 1, 5, and 10

Graphics:  ASPEED AST2400 BMC

Memory Capacity:  64GB

Memory Supported:  256GB

Memory Type:  DDR4

Memory Slots:  4 DIMM slots

Expansion Slots:  1 × PCIe 3.0 ×4

Error Detection:  ECC

TDP:  Up to 25W

Power Input:  12 V DC

Form Factor:  Flex-ATX
