Overview

The MBD-A2SAP-E-O is a Pico-ITX embedded server motherboard with an integrated Intel Atom E3940 SoC, supporting up to 8 GB DDR3L memory, dual Gigabit LAN, SATA, M.2 expansion, and HDMI/LVDS video — targeted at compact industrial or edge computing applications where low power and small footprint are key.



Specifications

Model Number:  MBD-A2SAP-E-O

Brand:  Supermicro

Alt Part Number(s):  MBD-A2SAP-E-O

Product Type:  Motherboard

Technical Description

Brand:  Supermicro

Model Number:  MBD-A2SAP-E-O

Processor Type:  Intel Atom

Processor Model:  E3940

Processor Core:  4 Cores, 4 threads

Processor Socket:  FCBGA-1296

Storage Interfaces:  1 SATA 3.0 (6Gbps) port

Network:  Dual Gigabit Ethernet (1GbE) LAN ports via the Intel I210-IT controller

Display Output:  1 HDMI port and 1 48-bit LVDS connector

USB:  2 × USB 3.0,2 × USB 2.0

Audio:  Realtek ALC888S

Graphics:  Integrated Intel HD

Memory Supported:   8GB

Memory Speed:  1866MHz

Memory Type:  DDR4

Memory Slots:  1 SO-DIMM slots

Expansion Slots:  1 × PCIe 4.0 ×16

Error Detection:  Non-ECC

TDP:  9.5W

Form Factor:  Pico-ITX
