PHISON B1201K01480GP02512G00 Pascari BA50P 2.5in 480GB SATA III Non-SED Solid State Drive

Specifications

Model Number:  B1201K01480GP02512G00

Brand:   PHISON

Alt Part Number(s):    B1201K01480GP02512G00

Product Type:  Solid State Drive



Technical Description

Brand:  PHISON

Model:  B1201K01480GP02512G00

Capacity: 480GB

Security: Non-SED

Form Factor: 2.5" SSD

SATA Interface: SATA Gen3

Compliance: Serial ATA Revision 3.2

Performance
Sequential Read: up to 530 MB/s
Sequential Write: up to 480 MB/s
Random Read: up to 90K IOPS
Random Write: up to 15K IOPS

Power Consumption
Active Read (Avg. RMS): < 2.1W
Active Write (Avg. RMS): < 2.8W
Idle: < 1.3W

Endurance/Reliability
MTBF: 2.0 million hours
UBER: < 1 sector per 10^17 bits read
DWPD: 1
TBW: 876TB

Environmental Specifications
Temperature Range:
Operating: 0°C ~ 70°C
Non-operating: -40°C ~ 85°C
Shock:
Operating: 1000G, 0.5ms
Non-operating: 1500G, 0.5ms
Vibration:
Operating: 3.08Grms (7 - 800Hz)
Non-operating: 20G (20 - 2000Hz)
Drop: 80cm height
Bending: 50N force

Certifications and Declarations: CE, FCC, BSMI, VCCI, UKCA, RCM, ICES, KCC, CB, UL

Compliant: RoHS compliant

Feature Support
Hardware Based Power Loss Data Protection
Thermal throttling
End-to-End Data Path Protection
TCG Opal 2.04
