Overview

Pelco EVO-05NMD Evolution 360 5MP Outdoor Dome Network Camera



Specifications

Model Number:  EVO-05NMD

Brand:  Pelco

Alt Part Number(s):  EVO-05NMD

Product Type:  Network Security Camera



Technical Description

Brand:  Pelco

Model:  EVO-05NMD

Series:  Evolution 360

Camera Signal:  Network IP

Connection Type:  Wired

Infrared Distance:  Non Infrared

Resolution:  5 Megapixel

Lens Type:  Fixed

Lens Size:  1.6mm

Mount Type:  Ceiling, Wall

Compression Method:  H.264, M-JPEG

Durability:  Vandal Resistant, Weather Resistant

Voltage:  12vDC, PoE

Image Device:  1/2.5-Inch CMOS Sensor

Minimum Scene Illumination:  0.2 lux = 50 IRE F/2.0 (6500k)

Operating Humidity:  Up to 98% (In accordance with BS EN 60068-2-30)

Operating Temperature:  -40 to +55°C (-40 to +131°F)

Power Consumption:  4.512W (PoE) / 3.276W (DC12V)

Privacy Zone:  10 configurable privacy regions

Protocols:  TCP/IP, HTTP, DHCP, DNS, NTP, FTP, SMTP, RSTP, uPNP

S/N Ratio:  45dB

Signal System:  NTSC, PAL

Video Output:  BNC

Weatherproof:  IP66

Processor:  Computer with 1Ghz 32-bit (x86) or 64-bit (x64) processor

Angle of View:  180° hemisphere

Motion Detection Tracking:  12 regions of interest; VMD; configurable response; adjustable characteristics

Automatic White Balance:  Auto White Balance (Range = approx. 2500K~8000K)

*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
