Model Number: M50FCP2UR312

Brand:  MITAC

Alt Part Number(s):  M50FCP2UR312

Product Type:  Server



Technical Description

Brand:  MITAC

Model: M50FCP2UR312

Product Description: Intel Server System M50FCP2UR312 - rack-mountable no CPU - 0 GB - no HDD

Type: Server - rack-mountable

Height (Rack Units): 2U

Processor: No CPU

Processor Socket: LGA4677 Socket-E

RAM: 0 GB (installed) / 12 TB (max) - DDR4 SDRAM

Storage Controller: RAID

Server Storage Bays: Hot-swap 3.5"

Hard Drive: No HDD

Optical Storage: No optical drive

Dimensions (WxDxH): 30.3 in x 17.2 in x 3.4 in

Product Form Factor: Rack-mountable - 2U

Embedded Security: Trusted Platform Module (TPM 2.0) Security Chip

Hot-Swap Bays Qty: 10

CPU: No CPU

Max CPU Qty: 2

CPU Socket: LGA4677 Socket-E

Motherboard Name: Intel Server Board M50FCP2SBSTD

Installed RAM Size: 0 GB (installed) / 12 TB (max)

RAM Technology: DDR4 SDRAM

RAM Form Factor: DIMM 288-pin

RAM Slots: 32 (total)

RAM Features: Load-Reduced DIMM (LRDIMM)

Hard Drive Type: No HDD

Storage Controller Type: RAID

RAID Levels: RAID 0, RAID 1, RAID 5, RAID 10

Optical Drive Type: No optical drive

Monitor Type: None

Drive Bays: 12 (total) / 12 (free) x hot-swap 3.5"

Interfaces:

2 x USB 3.0 (1 front, 1 rear)

2 x USB 2.0 (1 front, 1 rear)

1 x serial

Included Accessories:

Front I/O panel assembly

16 x DIMM slot blanks

Chassis with Quick Reference Label affixed to top cover

12 x 3.5" hot-swap drive carriers

2U server airduct

2 x processor carrier clips

2U Hot-swap backplane spare CYPHSBP2312

6 x 2U fan kit CYPFAN2UKIT

Cables Included:

I2C cable

Power splitter cable

Power Device Type: Power supply

Installed Power Supply Qty: 0



*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
