Kioxia KCM71VJE3T20 3.2TB E3.S PCIe5 CM7-V Solid State Drive
Overview
Kioxia KCM71VJE3T20 CM7-V is a 3.2TB E3.S PCIe 5.0 NVMe SSD with 3D TLC flash, delivering up to 14,000 MB/s read, 6,750 MB/s write, and 3 DWPD endurance. Built for data center workloads with 2.5M hours MTBF.
Specifications
Model Number: KCM71VJE3T20
Brand: Kioxia
Alt Part Number(s): KCM71VJE3T20
Product Type: Solid State Drive
Technical Description
Brand: Kioxia
Model: KCM71VJE3T20
SSD Capacity: 3.2 TB
Flash Type: 3D TLC
Interface: PCIe 5.0
Max 4KB Random Read: 2,700K IOPS
Max 4KB Random Write: 600K IOPS
MTBF: 2,500,000 hours
Power Consumption (Operational): 24 W
Power / Voltage Required: 12 V ±10%, 3.3 V ±15%
Width: 76 mm ±0.25 mm
Depth: 7.5 mm (+0.2 / -0.5 mm)
Height: 112.75 mm ±0.4 mm
Weight: 110 g
Features: E3.S form factor (7.5 mm), PCIe 5.0, NVMe 2.0 compliant, proprietary KIOXIA controller and 112-layer BiCS FLASH 3D TLC, Open Compute Project Datacenter NVMe SSD v2.0 support
Min Operating Temperature: 0°C
Max Operating Temperature: 76°C
Max Sequential Read: 14,000 MB/s
Max Sequential Write: 6,750 MB/s
Endurance: 3 DWPD
*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
Overview
Kioxia KCM71VJE3T20 CM7-V is a 3.2TB E3.S PCIe 5.0 NVMe SSD with 3D TLC flash, delivering up to 14,000 MB/s read, 6,750 MB/s write, and 3 DWPD endurance. Built for data center workloads with 2.5M hours MTBF.
Specifications
Model Number: KCM71VJE3T20
Brand: Kioxia
Alt Part Number(s): KCM71VJE3T20
Product Type: Solid State Drive
Technical Description
Brand: Kioxia
Model: KCM71VJE3T20
SSD Capacity: 3.2 TB
Flash Type: 3D TLC
Interface: PCIe 5.0
Max 4KB Random Read: 2,700K IOPS
Max 4KB Random Write: 600K IOPS
MTBF: 2,500,000 hours
Power Consumption (Operational): 24 W
Power / Voltage Required: 12 V ±10%, 3.3 V ±15%
Width: 76 mm ±0.25 mm
Depth: 7.5 mm (+0.2 / -0.5 mm)
Height: 112.75 mm ±0.4 mm
Weight: 110 g
Features: E3.S form factor (7.5 mm), PCIe 5.0, NVMe 2.0 compliant, proprietary KIOXIA controller and 112-layer BiCS FLASH 3D TLC, Open Compute Project Datacenter NVMe SSD v2.0 support
Min Operating Temperature: 0°C
Max Operating Temperature: 76°C
Max Sequential Read: 14,000 MB/s
Max Sequential Write: 6,750 MB/s
Endurance: 3 DWPD
*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
Original: $1,566.00
-70%$1,566.00
$469.80Description
