Overview

Kioxia KCD8DRUG7T68 CD8-R Series 7,680 GB PCIe 4.0, NVMe 1.4 Solid State Drive

Specifications

Model Number:  KCD8DRUG7T68

Brand:   Kioxia

Alt Part Number(s):    KCD8DRUG7T68

Product Type:  Solid State Drive



Technical Description

Brand:  Kioxia

Model:  KCD8DRUG7T68

Capacity: 7,680 GB (7.68TB)

Form Factor: 2.5-inch, 15mm height (U.2)

Interface: PCIe 4.0 x4, NVMe 1.4

Max Interface Speed: 64 GT/s

Flash Type: BiCS FLASH TLC (Triple-Level Cell)

Sequential Read (128 KiB): 7,100 MB/s

Sequential Write (128 KiB): 6,000 MB/s

Random Read (4 KiB): 1,150,000 IOPS

Random Write (4 KiB): 200,000 IOPS

Input Voltage: 12V ±10%, 3.3V ±15%

Active Power Consumption: 19W (typical)

Idle Power Consumption: 5W (typical)

MTTF: 2.5 million hours

DWPD: 1 (Drive Writes Per Day)

Operating Temp: 0°C to 75°C

Non-Operating Temp: -40°C to 85°C

Humidity: 5% to 95% RH (operating)

Vibration (Operating): 21.27 m/s² (2.17 Grms, 5–800 Hz)

Shock (Operating): 9,800 m/s² (1,000 G, 0.5 ms)

*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
