Overview

Kioxia KCD8DRUG3T84 CD8-R Series 3,840 GB PCIe 4.0 NVMe 1.4 BiCS FLASH TLC Solid State Drive

Specifications

Model Number:  KCD8DRUG3T84

Brand:   Kioxia

Alt Part Number(s):    KCD8DRUG3T84

Product Type:  Solid State Drive



Technical Description

Brand:  Kioxia

Model:  KCD8DRUG3T84

Capacity: 3,840 GB (3.84 TB)

Form Factor: 2.5-inch, 15 mm thickness

Interface: PCIe 4.0, NVMe 1.4

Maximum Interface Speed: 64 GT/s (PCIe Gen4 x4)

Flash Memory Type: BiCS FLASH TLC

Sequential Read (128 KiB): Up to 7,200 MB/s

Sequential Write (128 KiB): Up to 3,800 MB/s

Random Read (4 KiB): Up to 1,250K IOPS

Random Write (4 KiB): Up to 195K IOPS

Supply Voltage: 12 V ±10%, 3.3 V ±15%

Power Consumption (Active): 14 W (typical)

Power Consumption (Idle/Ready): 5 W (typical)

MTTF: 2,500,000 hours

Endurance (DWPD): 1

Operating Temperature: 0°C to 75°C

Non-operating Temperature: -40°C to 85°C

Operating Humidity: 5% to 95% RH

Operating Vibration: 21.27 m/s² (2.17 Grms, 5–800 Hz)

Operating Shock: 9.8 km/s² (1,000 G, 0.5 ms)
