HPE P87776-005 ProLiant Compute DL320 Gen12 is a 1U server powered by an Intel Xeon 6515P 16 core processor running at 2.3 GHz. It includes 64 GB DDR5 memory at 6400 MHz, supports up to 4 TB RAM, offers 8 drive bays, and features dual 1000 W power supplies with 10Gb Ethernet connectivity.
✨ New Arrivals Just Dropped!Explore
1 / 4
HPE P87776-005 ProLiant Compute DL320 Gen12 6515P Intel Xeon 16-Core 64GB DDR5 1U Server
Overview
Specifications
Model Number: P87776-005
Brand: HPE
Alt Part Number(s): P87776-005
Product Type: Server
Technical Description
Brand: HPE
Model: P87776-005
Cabinet Form Factor: 1U, GPU Server
Processor / Type: Xeon
Processor / Manufacturer: Intel
Processor / Number: 6515P
Processor / Clock Speed: 2.3 GHz
Max Turbo Frequency: 3.8 GHz
Multi-Core Technology: 16-Core
Processor / Installed Qty: 1
Cache Memory Installed Size: 72 MB
RAM / Technology: DDR5
RAM / Total Installed Size: 64 GB
RAM / Memory Speed: 6400 MHz
RAM Form Factor: RDIMM
RAM / Installed Qty: 1
RAM / Total Slots Qty: 16
RAM / Max Supported Size: 4 TB
Hard Drive / Size: 2.5"
Hard Drive / Bays Qty: 8
Networking Type: Ethernet
Data Link Protocol: Gigabit Ethernet
Network Controller: Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T Adapter
Storage Controller Type: MR408i-o
Power / Device Type: Power Supply
Power / Installed Qty: 2
Power / Provided (W): 1000 Watt
80 PLUS Certification: 80 PLUS Titanium
Interfaces & Connections: iLO Service; USB 3.2 Gen1; VGA; 2 USB 3.2; Dedicated iLO network
Front I/O Ports: iLO Service; USB 3.2 Gen1
Rear I/O Ports: VGA; 2 USB 3.2; Dedicated iLO network
Expansion Slots Total (Free): Up to 6 PCIe Gen5; 2 OCP 3.0 with Rich IO Processor
Width: 17.11 Inch
Depth: 23.92 Inch
Height: 1.69 Inch
Service & Support Type: Three years of parts; three years of labor; three years of on-site support coverage
Min Operating Temperature: 10 Celsius
Max Operating Temperature: 35 Celsius
Humidity Range Operating: 8% to 90%
*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
Overview
HPE P87776-005 ProLiant Compute DL320 Gen12 is a 1U server powered by an Intel Xeon 6515P 16 core processor running at 2.3 GHz. It includes 64 GB DDR5 memory at 6400 MHz, supports up to 4 TB RAM, offers 8 drive bays, and features dual 1000 W power supplies with 10Gb Ethernet connectivity.
Specifications
Model Number: P87776-005
Brand: HPE
Alt Part Number(s): P87776-005
Product Type: Server
Technical Description
Brand: HPE
Model: P87776-005
Cabinet Form Factor: 1U, GPU Server
Processor / Type: Xeon
Processor / Manufacturer: Intel
Processor / Number: 6515P
Processor / Clock Speed: 2.3 GHz
Max Turbo Frequency: 3.8 GHz
Multi-Core Technology: 16-Core
Processor / Installed Qty: 1
Cache Memory Installed Size: 72 MB
RAM / Technology: DDR5
RAM / Total Installed Size: 64 GB
RAM / Memory Speed: 6400 MHz
RAM Form Factor: RDIMM
RAM / Installed Qty: 1
RAM / Total Slots Qty: 16
RAM / Max Supported Size: 4 TB
Hard Drive / Size: 2.5"
Hard Drive / Bays Qty: 8
Networking Type: Ethernet
Data Link Protocol: Gigabit Ethernet
Network Controller: Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T Adapter
Storage Controller Type: MR408i-o
Power / Device Type: Power Supply
Power / Installed Qty: 2
Power / Provided (W): 1000 Watt
80 PLUS Certification: 80 PLUS Titanium
Interfaces & Connections: iLO Service; USB 3.2 Gen1; VGA; 2 USB 3.2; Dedicated iLO network
Front I/O Ports: iLO Service; USB 3.2 Gen1
Rear I/O Ports: VGA; 2 USB 3.2; Dedicated iLO network
Expansion Slots Total (Free): Up to 6 PCIe Gen5; 2 OCP 3.0 with Rich IO Processor
Width: 17.11 Inch
Depth: 23.92 Inch
Height: 1.69 Inch
Service & Support Type: Three years of parts; three years of labor; three years of on-site support coverage
Min Operating Temperature: 10 Celsius
Max Operating Temperature: 35 Celsius
Humidity Range Operating: 8% to 90%
*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
$9,449.00
