Gigabyte A620M GAMING X AX AMD Socket AM5 4 x DDR5 DIMM Micro ATX Gaming Desktop Motherboard
Overview
Gigabyte A620M GAMING X AX Gaming Desktop features an AMD AM5 socket supporting Ryzen 7000, 8000, and 9000 series CPUs with DDR5 memory up to 256 GB. It includes PCIe 4.0 expansion, M.2 and SATA storage, Wi-Fi 6E, Bluetooth 5.2, high-definition audio, and HDMI/DisplayPort outputs in a Micro ATX form factor.
Specifications
Model Number: A620M GAMING X AX
Brand: Gigabyte
Alt Part Number(s): A620M GAMING X AX
Product Type: Gaming Desktop Motherboard
Technical Description
Brand: Gigabyte
Model: A620M GAMING X AX
CPU Socket: AMD AM5
Supported CPUs: AMD Ryzen™ 7000 Series; AMD Ryzen™ 8000 Series; AMD Ryzen™ 9000 Series
Chipset: AMD A620
Memory Type: DDR5; up to 8000(OC) MT/s
Memory Slots: 4 DIMM; up to 256 GB
Memory Features: Dual channel; AMD EXPO™ support; XMP support
Integrated Graphics: DisplayPort 1.4 up to 3840 × 2160 @144 Hz; HDMI 2.1 up to 4096 × 2160 @60 Hz
Expansion Slot: 1 × PCIe x16 slot for dedicated GPU; PCIe 4.0 support depending on CPU
M.2 SSD Slot: 1 slot; PCIe 4.0 x4/x2
SATA Ports: 4 × SATA 6 Gb/s
RAID Support: RAID 0; RAID 1; RAID 10 for NVMe and SATA
LAN: Realtek GbE; 1 Gbps
Wi-Fi: Wi-Fi 6E; 2.4 GHz; 5 GHz; 6 GHz
Bluetooth: 5.2
Audio Codec: Realtek High Definition Audio
Audio Channels: 2-channel; 4-channel; 5.1-channel; 7.1-channel configurable
USB Ports: USB 3.2 Gen 2 Type-A; USB 3.2 Gen 2 Type-C
Display Outputs: HDMI; DisplayPort
Other I/O: RJ-45 LAN; audio jacks; PS/2 port
Cooling & Monitoring: Fan speed control; voltage monitoring; temperature monitoring; water cooling support
BIOS: AMI UEFI BIOS; Q-Flash; Q-Flash Plus
Software Support: Gigabyte Control Center
Bundled Software: Norton Internet Security OEM
OS Support: Windows 10 64-bit; Windows 11 64-bit
Form Factor: Micro ATX; 24.4 cm × 24.4 cm
*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
