The Chenbro RB23724E3RPCWFT is a 2U high-performance barebone server system designed for storage-intensive and mission-critical applications. It is part of the RB237 series, which focuses on providing maximum compute-to-storage density for data centres and cloud services.



Specifications

Model Number:  RB23724E3RPCWFT

Brand:  Chenbro

Alt Part Number(s):  RB23724E3RPCWFT

Product Type:  Barebone Server

Technical Description

Brand:  Chenbro

Model Number:  RB23724E3RPCWFT

Processor Type:  Intel Xeon Scalable (2nd Gen)

Processor Socket:  FCLGA3647 (Socket P)

Processor Core:  56 Cores / 112 Threads

Processor Power:  165W

Chipset Type:  Intel C624

Motherboard:  S2600WFTR

Networking:  Dual 10 GbE + management

Drive Bays:  12× 3.5″ hot‑swap (SAS/SATA)

Graphics Controller:  ASPEED AST2500 BMC

GPU Supported:  2 Cards (Low-profile / Half-length PCIe)

Front:  1 x USB 3.0, 1 x USB 2.0, and 1 x VGA

Rear: 2 x 10GbE Base-T (RJ-45), 1 x Dedicated Port, 3 x USB 3.0, and 1 x UID

Memory Capacity:  256GB

Memory Supported:  7.5TB

Memory channels:  12-Channel

Memory Slots:  24 × DDR4 DIMM

Expansion Slots:  8 PCIe cards

Cooling:  6 x hot-swap cooling fans (17K RPM)

Power Supply:  1+1 redundant 800W CRPS (80 Plus Platinum)

Form Factor:  2U Rackmount
