 ASUS RS720-E12-RS12U-27KW10G Dual Intel Xeon 6 32x DIMM DDR5 2U Server



Specifications

Model Number:  RS720-E12-RS12U-27KW10G

Brand:   ASUS

Alt Part Number(s):    RS720-E12-RS12U-27KW10G

Product Type:  Server



Technical Description

Brand:  ASUS

Model:  RS720-E12-RS12U-27KW10G

Form Factor: 2U Rackmount, GPU Servers

Processor / Type: Xeon

Processor / Manufacturer: Intel

RAM Form Factor: DIMM

RAM / Total Slots Qty: 32

RAM / Max Supported Size: 4 TB

Hard Drive / Interface Type: PCI Express; NVMe

Hard Drive / Bays Qty: 12

Power / Device Type: Power Supply

Power / Redundant Capable: Yes

Power / Redundant Scheme: 1+1

Power / Provided (W): 2700 Watt

Power / Voltage Required: 100-120V~/220-240V, 50-60Hz

80 PLUS Certification: 80 PLUS Titanium

Interfaces & Connections: 1 × Management Port, 2 × USB 3.2 Gen1 ports (Front), 2 × USB 3.2 Gen1 ports (Rear), 1 × Mini-DP port (Rear), 1 × RJ-45 Management LAN port (Rear), 1 × Debug port (Rear)

Expansion Slots Total (Free):
Total 10 expansion slots: 6 × PCIe Gen5 x8 or 3 × PCIe Gen5 x16 (FHFL), 2 × PCIe Gen5 x16 (FHHL), 2 × OCP3.0 Gen5 x16 (SFF)

Features: Extensive computing performance; Modular and scalable architecture; Large Storage Capacity; Optimized air cooling solution; Tool-less, easy-maintenance design

Min Operating Temperature: 10°C

Max Operating Temperature: 35°C



*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
