Overview

ASUS ESC8000-E12-32W from the ESC GPU server series features dual Intel Xeon processors with 128 cores and 32 DDR5 slots supporting up to 4 TB memory. It includes 8 dual-slot PCIe Gen5 GPU slots, multiple NVMe and hot-swap storage bays, redundant 3.2 KW power supplies, and high-speed networking for demanding AI and HPC workloads.



Specifications

Model Number: ESC8000-E12-32W

Brand:   ASUS

Alt Part Number(s):   ESC8000-E12-32W

Product Type:  Server



Technical Description

Brand:  ASUS

Model: ESC8000-E12-32W

Form Factor: 4U Rackmount, GPU Server

CPU Support: 2 × Intel® Xeon® 6 processors (LGA 4710)

Memory: 32 × DDR5 RDIMM slots, up to 4 TB

GPU Slots: Up to 8 × dual-slot PCIe Gen5 GPUs

PCIe Expansion: Multiple Gen5 slots for GPU, NIC, RAID/HBA cards

Storage: 8 × 2.5″ hot-swap bays; 2 × M.2 slots

NVMe Support: Up to 6 × U.2 NVMe drives

Networking: Dedicated management LAN; supports high-speed NIC/DPU cards

Power Supply: Redundant 3200 W Titanium (3+1 typical)

Management: BMC/IPMI; ASUS Control Center

Cooling: Tool-less GPU and system fans for easy maintenance



*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
