Overview

The APC Smart-UPS X 2200VA (SMX2200HV) is a line-interactive, rack/tower convertible uninterruptible power supply (UPS) designed to provide reliable, network-grade power protection for servers and other critical IT equipment in high-voltage environments.



Specifications

Model Number:  SMX2200HV

Brand:  APC

Alt Part Number(s):  SMX2200HV

Product Type:  UPS System

Technical Description

Brand:  APC

Model Number:  SMX2200HV

Series:  Smart-UPS X

Phase:  Single Phase

Input Voltage:  208 V

Output Voltage:  230 V

Input Frequency:  50 / 70 Hz

Receptacle Type:  (2) IEC 320 C19

Receptacle Details:  (8) IEC 320 C13

Backup/Run Time (Full Load):  9.8 Min

Backup/Run Time (Half Load):  25.3 Min

Battery Recharge Time:  3-Hour

Battery Chemistry:  Lead Acid

Cord Length:  8ft

Load Capacity (VA):  2200VA

Load Capacity (W):  1980W

Circuit Protection:  Circuit breaker

Form Factor:  4U Rackmount

Height: 17.01"

Width: 7.01"

Depth:  19.02"

*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
