Overview

 AMD Ryzen 9 9950X3D 100-000000719 delivers elite 16-core/32-thread performance with a 4.3 GHz base clock, 5.7 GHz boost, 128MB L3 cache, and 170W TDP, featuring Socket AM5, integrated Radeon Graphics, dual-channel DRAM support up to 192GB, and AMD EXPO/Ryzen technologies for top-tier computing workloads.



Specifications

Model Number:  100-000000719

Brand:   AMD

Alt Part Number(s):    100-000000719

Product Type:  Processor



Technical Description

Brand:  AMD

Model:  100-000000719

Family: Ryzen

Series: Ryzen 9000 Series

Form Factor: Desktops, Boxed Processor

Market Segment: Enthusiast Desktop

AMD PRO Technologies: No

Regional Availability: Global

Former Codename: Granite Ridge AM5

Processor Architecture: Zen 5

# of CPU Cores: 16

Multithreading (SMT): Yes

# of Threads: 32

Max. Boost Clock: Up to 5.7 GHz

Base Clock: 4.3 GHz

L1 Cache: 1280 KB

L2 Cache: 16 MB

L3 Cache: 128 MB

Default TDP: 170 W

Processor Technology for CPU Cores: TSMC 4nm FinFET

Processor Technology for I/O Die: TSMC 6nm FinFET

Package Die Count: 3

Unlocked for Overclocking: Yes

AMD EXPO Memory Overclocking Technology: Yes

Precision Boost Overdrive: Yes

Curve Optimizer Voltage Offsets: Yes

AMD Ryzen Master Support: Yes

CPU Socket: AM5

Supporting Chipsets: A620, X670E, X670, B650E, B650, X870E, X870, B840, B850

CPU Boost Technology: Precision Boost 2

Instruction Set: x86-64

Supported Extensions: AES, AVX512, AVX2, AVX, FMA3, MMX-plus, SSE2, SSE4.2, SSE4A, SSE4.1, SSE3, SSSE3, SSE, x86-64

Thermal Solution (PIB): Not Included

Recommended Cooler: Liquid cooler recommended for optimal performance

Max. Operating Temperature (Tjmax): 95 °C

OS Support: Windows 11 - 64-Bit Edition, Windows 10 - 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit

Native USB 3.2 Gen 2 (10Gbps): 4

Native USB 2.0 (480Mbps): 1

PCI Express Version: PCIe 5.0

Native PCIe Lanes (Total/Usable): 28 / 24

NVMe Support: Boot, RAID0, RAID1, RAID5, RAID10

System Memory Type: DDR5

Memory Channels: 2

Max. Memory: 192 GB

System Memory Subtype: UDIMM

ECC Support: Yes (Requires motherboard support)

Graphics Model: AMD Radeon Graphics

Graphics Core Count: 2

Graphics Frequency: 2200 MHz

USB Type-C DisplayPort Alternate Mode: Yes

Max Memory Speed:
          2x1R DDR5-5600
          2x2R DDR5-5600
          4x1R DDR5-3600
          4x2R DDR5-3600
