The XP1-S202SP05 is a 2U rackmount server barebone system manufactured by AIC (Advanced Industrial Computer). It is designed for high-density storage and high-performance computing



Specifications

Model Number:  XP1-S202SP05

Brand:  AIC

Alt Part Number(s):  XP1-S202SP05

Product Type:  Barebone Server

Technical Description

Brand:  AIC

Model Number:  XP1-S202SP05

Series:  SB202-SP

Processor Type:  Intel Xeon Scalable

Processor Core:  56 Core/112 Thread

Processor Power:  Up to 105W per CPU

Processor Socket:  Dual Socket P0 (LGA 3647)

Motherboard:  AIC Server Board Spica

Chipset Type:  Intel C620

Graphics Controller:  Integrated Aspeed AST2500

Ports:  2x USB 3.0 Type A Ports (rear), 1x VGA Port, 1x Serial Port, 2x RJ45 LAN Ports, 2x 10GbE SFP+ Ports (Optional BTO), 1x GbE RJ45 dedicated to BMC management Port

Networking:  Integrated Intel I350 dual-port GbE LAN

RAID Levels:  0, 1, 5, 10

Number of Drive Bays:  12x 3.5" Hot-swap drive bays, 2x 2.5" Hot-swap rear drive bays for OS

Expansion Slots:  2×PCIe 3.0 x16, 5×PCIe 3.0 x8 (low profile)

Memory Supported:  3TB

Memory Size:  256GB

Memory Technology:  DDR4 ECC Registered

Memory Speed:  Up to 2933MHz

Memory Slots:  12 (6 slots per CPU)

Power Supply:  800W 80+ Platinum Redundant

System Cooling:  3x 80x38mm System Fans

Form Factor:  2U Rackmount
